Dual Display Two Way Radio Walkie Talkie interphone from China manufacturer

Product Detail

Model No.: HG-UV58

Production Capacity: 100000/month

Delivery Date: Withing 1-20 working days

Means of Transport: Ocean,Land,Air;Express

Packing: Color Box Package

HG-UV58 is a well-received amateur radio and it is good looking, nice design and excellent performance.

HIGRADE HG-UV58 VHF136-174Mhz / UHF400-480Mhz Dual Display

Description:

HG-UV58 is a well-received amateur radio and it is good looking, nice design and excellent performance.

Main Functions:

Single band, dual display, dual standby	A/B band independent operation
128 groups channels storage	Shortcut menu operation mode
VFO & Memory channels scan	Emergency Alarm
Tri-color background light selectable	0~9 grades VOX selectable
PTT & ANI ID	FM radio and 25 stations storage
Voice companding	CTCSS/DCS coder & tone searching
	Wire clone & PC programmable
Wide/Narrow Band(25kHz/12.5kHz)	Transmitter time-out timer(TOT)
High/Low TX power selectable	Busy channel lock-out(BCLO)

Specifications:

Item number	HG-UV58
General
Frequency Range	70-108MHz(FM Receive only)
Frequency Range	136-174MHz
Channel No.	128
Frequency Stability	±2.5ppm
Antenna	High gain antenna
Antenna Impedance	50Ω
Operating Voltage	DC 7.4V
Mode of operation	Simple or semi-duplex
Dimension(W x H x D)	100 x 52 x 32 mm
Weight	250g(including battery, antenna)
Transmitter
Output power	4W / 0.5W
Modulation Mode	16kΦF3E / 11kΦF3E
Maximum deviation	<5kHz(Wide) / <2.5kHz(Narrow)
Spurious Radiation	<7μW
Adjacent Ch. power	≤-65dB(Wide) / ≤-60dB(Narrow)
Pre-emphasis characteristics	6dB
Current	≤1.6A(5W)
CTCSS/DCS deviation	0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
Intermediation sensitivity	8-12mv
Intermediation distortion	<10%
